G Class SWB (W463 2008) Versions

Mercedes Benz G Class SWB (W463 2008) 350 BlueTEC Cabrio Specs

(2011 - 2012) - Technical Specifications for Years 2011, 2012

Diesel

182.3 cu-in
2987 cm³

V 6

208 HP
211 PS / 155 kW

398 lb-ft
540 Nm

109 Mph
175 km/h

Mercedes Benz G Class SWB (W463 2008) 350 BlueTEC Cabrio Body, Model and Production details

Generation :	W463 - 2008 Facelift

Body :	TT

Num. of Doors :	2 doors


Mercedes Benz G Class SWB (W463 2008) 350 BlueTEC Cabrio Engine Technical Data

Engine type - Number of cylinders :	V 6

Engine Code :	Daimler-Benz OM642 DE30

Fuel type :	Diesel

Fuel System :	Common Rail

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	182.3 cu-in / 2987 cm³

Bore x Stroke :	3.27 x 3.62 inches 83.0 x 92.0 mm

Number of valves :	24 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	18

Horsepower :	208 HP / 211 PS / 155 kW @ 3400 rpm

Maximum torque :	398 lb-ft / 540 Nm @ 1600 - 2400 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	7 speed Automatic


Mercedes Benz G Class SWB (W463 2008) 350 BlueTEC Cabrio Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	17 MPG 13.6 L/100 km 21 MPG UK

Fuel Consumption - Economy - Open road NEDC :	24 MPG 9.8 L/100 km 29 MPG UK

Fuel Consumption - Economy - Combined NEDC :	21 MPG 11.2 L/100 km 25 MPG UK

Range :	533 miles / 857 km

Fuel Tank Capacity :	25.4 gallons 96 L 21.1 UK gallons

CO2 emissions :	295 g/km (Mercedes Benz)

Emission standard :	Euro 5

Catalytic converter :	Y

Mercedes Benz G Class SWB (W463 2008) 350 BlueTEC Cabrio Performance

Top Speed :	109 Mph / 175 km/h

Acceleration 0 to 60 mph (0 to 96 Km/h) :	8.3 s

Acceleration 0 to 100 km/h (0 to 62 mph) :	8.8 s


Mercedes Benz G Class SWB (W463 2008) 350 BlueTEC Cabrio Size, Dimensions, Aerodynamics and Weight

Wheelbase :	94.49 inches / 240.0 cm

Length :	167.6 inches / 425.7 cm

Width :	69.29 inches / 176.0 cm

Height :	76.42 inches / 194.1 cm

Front Axle :	58.07 inches / 147.5 cm

Rear Axle :	58.07 inches / 147.5 cm

Ground clearance :	8.07 inches / 20.5 cm

Approach angle (deg) :	36.0°

Departure angle (deg) :	27.0°

Max. Towing Capacity Weight :	6283 lbs / 2850 kg

Aerodynamic drag coefficient - Cx :	0.54

Curb Weight :	4949 lbs / 2245 kg

Weight/Power Output Ratio :	10.6 kg/hp


Mercedes Benz G Class SWB (W463 2008) 350 BlueTEC Cabrio Interior size, Dimensions

Num. of Seats :	4 seats

Seat distribution :	2+2

Trunk / Boot capacity :	8.4 cu-ft / 238 L

Trunk / Boot First Row :	55.8 cu-ft / 1580 L

Trunk / Boot Second Row :	8.8 cu-ft / 250 L


Mercedes Benz G Class SWB (W463 2008) 350 BlueTEC Cabrio Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Front Tyres - Rims dimensions :	265/70 R16

Rear Tyres - Rims dimensions :	265/70 R16

Front Wheels Width :	7.5"

Rear Wheels Width :	7.5"

Turning circle :	37.1 feet / 11.3 m

Front Suspension :	Rigid Axle. Coil Springs.

Rear Suspension :	Rigid Axle. Coil Springs.
