A5 Sportback 2020 Versions

Audi A5 Sportback 2020 45 TFSI 245HP quattro Specs

(2020 - 2020) - Technical Specifications for 2020

Petrol

121.1 cu-in
1984 cm³

Inline 4

242 HP
245 PS / 180 kW

272 lb-ft
370 Nm

155 Mph
250 km/h

32 MPG
7.3 L/100 km
39 MPG UK

Audi A5 Sportback 2020 45 TFSI 245HP quattro Body, Model and Production details

Generation :	A5 Type F5 - 2020 Facelift

Body :	Hatchback

Num. of Doors :	5 doors


Audi A5 Sportback 2020 45 TFSI 245HP quattro Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	VW EA888 DKN

Fuel type :	Petrol

Fuel System :	Direct Injection

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	121.1 cu-in / 1984 cm³

Bore x Stroke :	3.25 x 3.65 inches 82.5 x 92.8 mm

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	9.6

Horsepower :	242 HP / 245 PS / 180 kW @ 5500-6000 rpm

Maximum torque :	272 lb-ft / 370 Nm @ 1600-4300 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	7 speed Dualclutch Automatic


Audi A5 Sportback 2020 45 TFSI 245HP quattro Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	28 MPG 8.4 L/100 km 34 MPG UK

Fuel Consumption - Economy - Open road NEDC :	45 MPG 5.2 L/100 km 54 MPG UK

Fuel Consumption - Economy - Combined NEDC :	37 MPG 6.4 L/100 km 44 MPG UK

Fuel Consumption - Economy - Low WLTP:	22 MPG 10.5 L/100 km 27 MPG UK

Fuel Consumption - Economy - Medium WLTP:	32 MPG 7.4 L/100 km 38 MPG UK

Fuel Consumption - Economy - High WLTP:	37 MPG 6.3 L/100 km 45 MPG UK

Fuel Consumption - Economy - Extra high WLTP:	34 MPG 7 L/100 km 40 MPG UK

Fuel Consumption - Economy - Combined WLTP:	32 MPG 7.3 L/100 km 39 MPG UK

Range :	563 miles / 906 km

Range (WLTP):	493 miles / 794 km

Fuel Tank Capacity :	15.3 gallons 58 L 12.8 UK gallons

CO2 emissions :	150 g/km (Audi)

CO2 emissions WLTP :	166 g/km (Audi)

Emission standard :	Euro 6d-TEMP-EVAP-ISC

Catalytic converter :	Particle Filter

Audi A5 Sportback 2020 45 TFSI 245HP quattro Performance

Top Speed :	155 Mph / 250 km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	6.0 s


Audi A5 Sportback 2020 45 TFSI 245HP quattro Size, Dimensions, Aerodynamics and Weight

Wheelbase :	111.18 inches / 282.4 cm

Length :	187.28 inches / 475.7 cm

Width :	72.56 inches / 184.3 cm

Width with mirrors :	79.88 inches / 202.9 cm

Height :	54.57 inches / 138.6 cm

Front Axle :	62.48 inches / 158.7 cm

Rear Axle :	61.73 inches / 156.8 cm

Max. Towing Capacity Weight :	3748 lbs / 1700 kg

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	3627 lbs / 1645 kg

Dry Weight :	3406 lbs / 1545 kg

Weight/Power Output Ratio :	6.7 kg/hp


Audi A5 Sportback 2020 45 TFSI 245HP quattro Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	from 16.4 cu-ft / 465 L

Trunk / Boot First Row :	45.2 cu-ft / 1280 L


Audi A5 Sportback 2020 45 TFSI 245HP quattro Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	225/50 R17

Rear Tyres - Rims dimensions :	225/50 R17

Turning circle :	38.4 feet / 11.7 m

Front Suspension :	Multi-link. Coil Springs. Anti-roll bar.

Rear Suspension :	Multi-link. Coil Springs. Anti-roll bar.
