Saab 9 5 2.3 Turbo Aero Specs

(2001 - 2005) - Technical Specifications for Years 2001, 2002, 2003, 2004, 2005

Petrol

2290 cm³
139.7 cu-in

Inline 4

250 PS
247 HP / 184 kW

350 Nm
258 lb-ft

250 km/h
155 Mph

Saab 9 5 2.3 Turbo Aero Body, Model and Production details

Body :	-


Saab 9 5 2.3 Turbo Aero Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Petrol

Fuel System :	MPI

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	2290 cm³ / 139.7 cu-in

Bore x Stroke :	90.0 x 90.0 mm 3.54 x 3.54 inches

Number of valves :	16 Valves

Aspiration :	Turbo + Intercooler

Compression Ratio :	9.3

Horsepower :	250 PS / 247 HP / 184 kW @ 5300 rpm

Maximum torque :	350 Nm / 258 lb-ft @ 1900 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	5 speed Manual


Saab 9 5 2.3 Turbo Aero Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	12.8 L/100 km 22 MPG UK 18 MPG US

Fuel Consumption - Economy - Open road NEDC :	6.4 L/100 km 44 MPG UK 37 MPG US

Fuel Consumption - Economy - Combined NEDC :	8.8 L/100 km 32 MPG UK 27 MPG US

Range :	795 km / 494 miles

Fuel Tank Capacity :	70 L 18.5 US gallons 15.4 UK gallons

CO2 emissions :	209 g/km (Saab)


Saab 9 5 2.3 Turbo Aero Size, Dimensions, Aerodynamics and Weight

Wheelbase :	270.3 cm / 106.42 inches

Length :	480.5 cm / 189.17 inches

Width :	179.2 cm / 70.55 inches

Height :	144.9 cm / 57.05 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1495 kg / 3296 lbs

Weight/Power Output Ratio :	6 kg/hp


Saab 9 5 2.3 Turbo Aero Interior size, Dimensions

Trunk / Boot capacity :	500 L / 17.7 cu-ft


Saab 9 5 2.3 Turbo Aero Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Front Tyres - Rims dimensions :	225/45 R17

Rear Tyres - Rims dimensions :	225/45 R17

Steering wheel lock-to-lock :	2.9 turns

Front Suspension :	Independent McPherson. coil springs. Anti-roll bar

Rear Suspension :	Multi-link. Coil springs. Anti-roll bar
