Hyundai i30 Tourer 1.6 CRDi 110HP Specs

(2017 - 2020) - Technical Specifications for Years 2017, 2018, 2019, 2020

Diesel

96.5 cu-in
1582 cm³

Inline 4

109 HP
110 PS / 81 kW

206 lb-ft
280 Nm

117 Mph
188 km/h

Hyundai i30 Tourer 1.6 CRDi 110HP Body, Model and Production details

Generation :	i30 PD

Body :	Estate

Num. of Doors :	5 doors


Hyundai i30 Tourer 1.6 CRDi 110HP Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	96.5 cu-in / 1582 cm³

Bore x Stroke :	3.04 x 3.33 inches 77.2 x 84.5 mm

Number of valves :	16 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	16.0

Horsepower :	109 HP / 110 PS / 81 kW @ 4000 rpm

Maximum torque :	206 lb-ft / 280 Nm @ 1500-2500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio: 6th Gear Ratio: Reverse Gear Ratio: 9.3

Clutch Type :	Dry single disc clutch


Hyundai i30 Tourer 1.6 CRDi 110HP Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	57 MPG 4.1 L/100 km 69 MPG UK

Fuel Consumption - Economy - Open road NEDC :	67 MPG 3.5 L/100 km 81 MPG UK

Fuel Consumption - Economy - Combined NEDC :	64 MPG 3.7 L/100 km 76 MPG UK

Range :	840 miles / 1351 km

Fuel Tank Capacity :	13.2 gallons 50 L 11 UK gallons

CO2 emissions :	96 g/km (Hyundai)

Emission standard :	Euro 6

Hyundai i30 Tourer 1.6 CRDi 110HP Performance

Top Speed :	117 Mph / 188 km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	11.3 s


Hyundai i30 Tourer 1.6 CRDi 110HP Size, Dimensions, Aerodynamics and Weight

Wheelbase :	104.33 inches / 265.0 cm

Length :	180.51 inches / 458.5 cm

Width :	70.67 inches / 179.5 cm

Height :	57.68 inches / 146.5 cm

Front Axle :	61.93 inches / 157.3 cm

Rear Axle :	62.24 inches / 158.1 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	3053 lbs / 1385 kg

Weight/Power Output Ratio :	12.6 kg/hp


Hyundai i30 Tourer 1.6 CRDi 110HP Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	21.3 cu-ft / 602 L

Trunk / Boot First Row :	58.3 cu-ft / 1650 L


Hyundai i30 Tourer 1.6 CRDi 110HP Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	195/65 R15

Rear Tyres - Rims dimensions :	195/65 R15

Front Wheels Width :	6.0"

Rear Wheels Width :	6.0"

Steering :	Rack and pinion Electric

Steering wheel lock-to-lock :	2.6 turns

Steering ratio :	13.4

Front Suspension :	MacPherson struts. Coil springs.

Rear Suspension :	Coil Springs.
