Make

Biscayne 4th Gen 4 Door Sedan 1969 Versions

Chevrolet Biscayne 4th Gen 4 Door Sedan 1969 350 V8 Turbo-Fire 255HP Hydra-Matic 3-speed Specs

(1968 - 1969) - Technical Specifications for Years 1968, 1969

Petrol

349.8 cu-in
5733 cm³

V 8

254 HP
258 PS / 190 kW

365 lb-ft
495 Nm

Chevrolet Biscayne 4th Gen 4 Door Sedan 1969 350 V8 Turbo-Fire 255HP Hydra-Matic 3-speed Body, Model and Production details

Generation :	Biscayne 4th Generation - 1969 Facelift

Body :	Sedan

Num. of Doors :	4 doors


Chevrolet Biscayne 4th Gen 4 Door Sedan 1969 350 V8 Turbo-Fire 255HP Hydra-Matic 3-speed Engine Technical Data

Engine type - Number of cylinders :	V 8

Engine Code :	GM L48 350

Fuel type :	Petrol

Fuel System :	Carburetor

Lubrication :	See oil information Engine oil capacity (with filter): 3.8 L
Engine Cooling - Capacity :	15.96 quarts / 15.1 L

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	349.8 cu-in / 5733 cm³

Bore x Stroke :	4 x 3.48 inches 101.6 x 88.4 mm

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	9.0

Horsepower :	254 HP / 258 PS / 190 kW @ 4800 rpm

Maximum torque :	365 lb-ft / 495 Nm @ 3200 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	3 speed Automatic Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: Reverse Gear Ratio: 1.93 Final Drive Ratio: 2.73


Chevrolet Biscayne 4th Gen 4 Door Sedan 1969 350 V8 Turbo-Fire 255HP Hydra-Matic 3-speed Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	25.1 gallons 95 L 20.9 UK gallons

Chevrolet Biscayne 4th Gen 4 Door Sedan 1969 350 V8 Turbo-Fire 255HP Hydra-Matic 3-speed Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Chevrolet Biscayne 4th Gen 4 Door Sedan 1969 350 V8 Turbo-Fire 255HP Hydra-Matic 3-speed Size, Dimensions, Aerodynamics and Weight

Wheelbase :	119.02 inches / 302.3 cm

Length :	215.91 inches / 548.4 cm

Width :	79.8 inches / 202.7 cm

Height :	55.91 inches / 142.0 cm

Front Axle :	62.52 inches / 158.8 cm

Rear Axle :	62.4 inches / 158.5 cm

Ground clearance :	6.3 inches / 16.0 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	3920 lbs / 1778 kg

Weight/Power Output Ratio :	6.9 kg/hp


Chevrolet Biscayne 4th Gen 4 Door Sedan 1969 350 V8 Turbo-Fire 255HP Hydra-Matic 3-speed Interior size, Dimensions

Num. of Seats :	6 seats

Seat distribution :	3+3

Front legroom :	42.6 inches / 108.2 cm

Rear seat legroom :	38.5 inches / 97.8 cm

Front head room :	38.9 inches / 98.8 cm

Rear head room :	37.99 inches / 96.5 cm

Trunk / Boot capacity :	-


Chevrolet Biscayne 4th Gen 4 Door Sedan 1969 350 V8 Turbo-Fire 255HP Hydra-Matic 3-speed Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Drums (- inches / - mm)

Rear Brakes - Disc dimensions :	Drums (- inches / - mm)

Front Tyres - Rims dimensions :	8.25/- R14

Rear Tyres - Rims dimensions :	8.25/- R14

Turning circle :	43.6 feet / 13.3 m

Front Suspension :	Independent. Wishbone. Coil Springs.

Rear Suspension :	Rigid Axle. Coil Springs.
