E34 5 Series Versions

BMW E34 5 Series 520i Specs

(1990 - 1992) - Technical Specifications for Years 1990, 1991, 1992

Petrol

121.5 cu-in
1991 cm³

Inline 6

148 HP
150 PS / 110 kW

140 lb-ft
190 Nm

134 Mph
216 km/h

BMW E34 5 Series 520i Body, Model and Production details

Generation :	E34

Body :	-

Num. of Doors :	4 doors


BMW E34 5 Series 520i Engine Technical Data

Engine type - Number of cylinders :	Inline 6

Engine Code :	M50B20

Fuel type :	Petrol

Fuel System :	Bosch DME M3.1

Engine Alignment :	Longitudinal

Engine displacement :	121.5 cu-in / 1991 cm³

Bore x Stroke :	3.15 x 2.6 inches 80 x 66 mm

Number of valves :	24 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	10.5

Horsepower :	148 HP / 150 PS / 110 kW @ 5900 rpm

Maximum torque :	140 lb-ft / 190 Nm @ 4700 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	5 speed Manual


BMW E34 5 Series 520i Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Open road:	34 MPG 6.9 L/100 km 41 MPG UK

Fuel Consumption - Economy - Highway:	28 MPG 8.5 L/100 km 33 MPG UK

Fuel Consumption - Economy - City:	17 MPG 13.9 L/100 km 20 MPG UK

Fuel Tank Capacity :	21.1 gallons 80 L 17.6 UK gallons


BMW E34 5 Series 520i Size, Dimensions, Aerodynamics and Weight

Wheelbase :	108.7 inches / 276.1 cm

Length :	185.83 inches / 472 cm

Width :	68.94 inches / 175.1 cm

Height :	55.59 inches / 141.2 cm

Aerodynamic drag coefficient - Cx :	0.31

Curb Weight :	3142 lbs / 1425 kg

Weight/Power Output Ratio :	9.5 kg/hp


BMW E34 5 Series 520i Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	16.2 cu-ft / 460 L


BMW E34 5 Series 520i Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Discs (11.89 inches / 302 mm)

Rear Brakes - Disc dimensions :	Discs (11.81 inches / 300 mm)

Front Tyres - Rims dimensions :	195/65 R15

Rear Tyres - Rims dimensions :	195/65 R15

Front Suspension :	Double Pivot MacPherson strut suspension

Rear Suspension :	Track link semi trailing arm suspension
